2.3CompatibletransducersforAxiom™+R
VMultifunctiondisplays
Axiom™+RVvariantMultifunctionDisplays(MFDs)includeabuilt-insonarmoduleandcanbe
connecteddirectlytocompatibletransducersusingthe25–pintransducerconnectorontherearof
thedisplay.
Compatibletransducers:
•RealVision™3Dtransducers
•DownVision™transducersusingavailableadaptorcables.RefertoChapter9Sparesand
accessoriesforalistofavailableadaptorcables.
•CHIRPconicalbeamtransducersusingavailableadaptorcables.RefertoChapter9Sparesand
accessoriesforalistofavailableadaptorcables.
•Non-CHIRPtransducercanbeconnectedusingavailableadaptorcables.RefertoChapter9
Sparesandaccessoriesforalistofavailableadaptorcables.RefertotheRaymarine®website
forcompatibletransducers:www.raymarine.com/transducers.
Note:
ChartplotteronlyvariantAxiom™+MFDsrequireanetwork edsonarmoduletoenablesonar
features.
R ealVisiontransducers
ThetransducerslistedbelowcanbeconnecteddirectlytoRealVision™3DvariantMFDs.
1
•R V-100RealVision™3Dplastictransommounttransducer(A80464)
2
•R V-200RealVision™3Dbronze0°thru-hullall-in-onetransducer(A80465)
•RV-212PandRV-212SRealVision™3Dbronze12°thru-hullsplit-pairtransducers
(T70318)
–RV-212Pporttransducer(A80466)
–RV-212Sstarboardtransducer(A80467)
•RV-220PandRV-220SRealVision™3Dbronze20°thru-hullsplit-pairtransducers
(T70319)
–RV-220Pporttransducer(A80468)
–RV-220Sstarboardtransducer(A80469)
3
•R V-300RealVision™3Dplastic0°thru-hullall-in-onetransducer(A80470)
•RV-312PandRV-312SRealVision™3Dplastic12°thru-hullsplit-pairtransducers
(T70320)
–RV-312Pporttransducer(A80471)
–RV-312Sstarboardtransducer(A80472)
•RV-320PandRV-320SRealVision™3Dplastic20°thru-hullsplit-pairtransducers
(T70321)
–RV-320Pporttransducer(A80473)
16

Raymarine AXIOM+ Series Specifications

General

Display Sizes	7", 9", 12", 16"
Display Type	IPS LCD
Touchscreen	Yes
Operating System	LightHouse 3
Waterproof Rating	IPX6/IPX7
RAM	4 GB
Internal Storage	16 GB
Radar Support	Yes
Chartplotter	Yes
Brightness	1500 nits
Processor	Quad-core
Connectivity	Wi-Fi, Bluetooth
GPS	Built-in GPS/GLONASS
Networking	NMEA 2000
Sonar	Supports CHIRP, RealVision 3D, SideScan, DownVision
Video Input	Yes
Operating Voltage	12/24 V DC
Display Resolution	7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
