Raymarine AXIOM+ Series User Manual

4.3NMEA2000(Sea
Talkng®)connection
TheMFDcantransmitandreceivedatafromdevicesconnectedonacompliantCANbusnetwork
thattheMFDisalsoconnectedto.TheMFDisconnectedtothebackboneusingtheDeviceNet
connectoronthePower/NMEA2000cable.
1.P ower/NMEA2000cableconnectstotherearoftheMFD.
2.DeviceNet(Micro-C5pinmale)connectorconnectstoNMEA2000networkorSeaTalkng®via
adaptorcable.
3.DeviceNet(5pinfemale)connector.
4.AdaptorcableconnectstoSeaTalkng®backboneorDeviceNetspurcableconnectstoNMEA
2000network.Availablecables
•A06045—FemaleDeviceNettoSea Talkng®cable,shown.
•E05026—FemaleDeviceNettobareendwires.
Note:
1.Sea Talkng®andNMEA2000devicesmustbeconnectedtoacorrectlyterminatedbackbone
thattheMFDisalsoconnectedto.DevicescannotbeconnecteddirectlytotheMFD.
2.RefertotheinstructionssuppliedwithyourSeaTalkng®/NMEA2000devicefordetailson
creatingabackbone.
4.4T ransducerconnection
IfyourMFDincludesabuilt-insonarmodulethenyoucanconnectatransducertoyourMFD.
Note:
R ealVision™transducersconnectdirectly,allothertransducertyperequireanadaptorcable.
Connections45

Raymarine AXIOM+ Series Specifications

General

Display Sizes	7", 9", 12", 16"
Display Type	IPS LCD
Touchscreen	Yes
Operating System	LightHouse 3
Waterproof Rating	IPX6/IPX7
RAM	4 GB
Internal Storage	16 GB
Radar Support	Yes
Chartplotter	Yes
Brightness	1500 nits
Processor	Quad-core
Connectivity	Wi-Fi, Bluetooth
GPS	Built-in GPS/GLONASS
Networking	NMEA 2000
Sonar	Supports CHIRP, RealVision 3D, SideScan, DownVision
Video Input	Yes
Operating Voltage	12/24 V DC
Display Resolution	7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
