Raymarine AXIOM+ Series User Manual

Axiom™9Axiom™12
A
265.03mm(10
.43in)314mm(12.36in)
B
187 .81(7.39in)226.72mm(8.93in)
C
76.
71mm(3.02in)76.2mm(3in)
D
65mm(2.56in)65mm(2.56in)
E
•S
traightconnectors=178mm(7.01
in)
•Right-angledconnectors=158mm
(6.22in)
•Straightconnectors=178mm(7.01
in)
•Right-angledconnectors=158mm
(6.22in)
Axiom9and12surfaceandflushmountdimensions
Axiom™9Axiom™12
A
244.08mm(9 .64in)314mm(12.36in)
B
157 .78mm(6.21in)217mm(8.54in)
C
8mm(0 .31in)
D
27 .05mm(1.06in)Maximum
E
157mm6. 18in)222mm(8.74in)
F
178mm(7 .01in)
G
19 .05mm(0.75in)Maximum
Note:
Therearmountbrack etsshownintheillustrationaresuppliedwiththeAxiom™9,Thebrackets
suppliedwiththeAxiom™12lookdifferent.
3.2Mountingoptions
Y ourproductcanbemountedinvariouswaystosuitanyinstallationrequirements.
30

Raymarine AXIOM+ Series Specifications

General

Display Sizes	7", 9", 12", 16"
Display Type	IPS LCD
Touchscreen	Yes
Operating System	LightHouse 3
Waterproof Rating	IPX6/IPX7
RAM	4 GB
Internal Storage	16 GB
Radar Support	Yes
Chartplotter	Yes
Brightness	1500 nits
Processor	Quad-core
Connectivity	Wi-Fi, Bluetooth
GPS	Built-in GPS/GLONASS
Networking	NMEA 2000
Sonar	Supports CHIRP, RealVision 3D, SideScan, DownVision
Video Input	Yes
Operating Voltage	12/24 V DC
Display Resolution	7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
