UsingR
earmountkit
A
201. 1mm(7.92in)
B
133mm(5.24in)
C
8mm(0 .32in)
D
•Surfacemounting=19 .05mm(0.75in)Maximum
•Flushmounting=27.05mm(1.06in)Maximum
E
•S traightconnectors=218mm(8.58in)
•Right-angledconnectors=198mm(7.79in)
F
73mm(2.87in)
G
132mm(5.2in)
Axiom9and12trunnionmountdimensions
Installation29

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Raymarine AXIOM+ Series and is the answer not in the manual?

Raymarine AXIOM+ Series Specifications

General IconGeneral
Display Sizes7", 9", 12", 16"
Display TypeIPS LCD
TouchscreenYes
Operating SystemLightHouse 3
Waterproof RatingIPX6/IPX7
RAM4 GB
Internal Storage16 GB
Radar SupportYes
ChartplotterYes
Brightness1500 nits
ProcessorQuad-core
ConnectivityWi-Fi, Bluetooth
GPSBuilt-in GPS/GLONASS
NetworkingNMEA 2000
SonarSupports CHIRP, RealVision 3D, SideScan, DownVision
Video InputYes
Operating Voltage12/24 V DC
Display Resolution7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
