P
owerdistribution
Recommendationsandbestpractice.
Theproductissuppliedwithapowercable,eitherasaseparateitemoracaptivecable
permanentlyattachedtotheproduct.Onlyusethepowercablesuppliedwiththeproduct.Do
NOTuseapowercabledesignedfor,orsuppliedwith,adifferentproduct.
Refertothe
Powerconnection
sectionformoreinformationonhowtoidentifythewiresinyour
product’
spowercable,andwheretoconnectthem.
Seebelowformoreinformationonimplementationforsomecommonpowerdistributionscenarios:
Important:
Whenplanningandwiring,tak eintoconsiderationotherproductsinyoursystem,someofwhich
(e.g.sonarmodules)mayplacelargepowerdemandpeaksonthevessel’selectricalsystem,
whichmayimpactthevoltageavailabletootherproductsduringthepeaks.
Theinformationprovidedbelowisforguidanceonly,tohelpprotectyourproduct.Itcovers
commonvesselpowerarrangements,butdoesNOTcovereveryscenario.Ifyouareunsure
howtoprovidethecorrectlevelofprotection,pleaseconsultanauthorizeddealerorasuitably
qualifiedprofessionalmarineelectrician.
Implementationconnectiontodistributionpanel(R ecommended)
1
W aterprooffuseholdercontainingasuitably-ratedinlinefusemustbefitted.
Forsuitablefuserating,referto:
In-linefuseandthermalbreakerratings
.
2
Productpowercable .
3
Drainwireconnectionpoint.
Itisrecommendedthatthesuppliedpowercableisconnectedtoasuitablebreak erorswitchon
thevessel'sdistributionpanelorfactory-fittedpowerdistributionpoint.
Thedistributionpointshouldbefedfromthevessel’sprimarypowersourceby8AWG(8.36mm
2
)
cable.
Ideally,allequipmentshouldbewiredtoindividualsuitably-ratedthermalbreakersorfuses,with
appropriatecircuitprotection.Wherethisisnotpossibleandmorethan1itemofequipmentshares
abreaker,useindividualin-linefusesforeachpowercircuittoprovidethenecessaryprotection.
