Raymarine AXIOM+ Series User Manual

1
P ositive(+)bar
2
Negative(-)bar
3Circuitbreak er
4
W aterprooffuseholdercontainingasuitably-ratedinlinefusemustbefitted.
Forsuitablefuserating,referto:
In-linefuseandthermalbreakerratings .
Important:
Observetherecommendedfuse/break erratingsprovidedintheproduct’sdocumentation,
howeverbeawarethatthesuitablefuse/breakerratingisdependentonthenumberofdevices
beingconnected.
Implementation—directconnectiontobattery
•Whereconnectiontoapowerdistributionpanelisnotpossible,thepowercablesuppliedwith
yourproductmaybeconnecteddirectlytothevessel' sbattery,viaasuitablyratedfuseorbreaker.
•ThepowercablesuppliedwithyourproductmayNOTincludeaseparatedrainwire.Ifthisisthe
case,onlythepowercable’sredandblackwiresneedtobeconnected.
•IfthepowercableisNOTsuppliedwithafittedinlinefuse,youMUSTfitasuitablyratedfuseor
breakerbetweentheredwireandthebattery’spositiveterminal.
•Refertotheinlinefuseratingsprovidedintheproduct’sdocumentation.
•Ifyouneedtoextendthelengthofthepowercablesuppliedwithyourproduct,ensureyou
observethededicated
Powercableextensions adviceprovidedintheproduct’sdocumentation.
Connections
41

Raymarine AXIOM+ Series Specifications

General

Display Sizes	7", 9", 12", 16"
Display Type	IPS LCD
Touchscreen	Yes
Operating System	LightHouse 3
Waterproof Rating	IPX6/IPX7
RAM	4 GB
Internal Storage	16 GB
Radar Support	Yes
Chartplotter	Yes
Brightness	1500 nits
Processor	Quad-core
Connectivity	Wi-Fi, Bluetooth
GPS	Built-in GPS/GLONASS
Networking	NMEA 2000
Sonar	Supports CHIRP, RealVision 3D, SideScan, DownVision
Video Input	Yes
Operating Voltage	12/24 V DC
Display Resolution	7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
