Raymarine AXIOM+ Series User Manual

Axiom™7+Axiom™9+Axiom™12+
Bluetooth:
1xBluetoothV4.0
LEN(L
oadEquivalency
Number):
1
S torage
Axiom™7Axiom™9Axiom™12
Internal:
16GBSolidS
tate
ExternalmicroSDcard:1xMicroSD XCcardslot
External(via
RCR-SDUSB
accessory):
•1xSDcardslot
•1xUSBA
External(viaRCR-2
accessory)
2xMicroSDHCcardslots
8.2R ealVision™3Dsonarspecification
ThefollowingspecificationonlyappliestoRealVision™3Dproducts.
Channels:•1xCHIRPsonar
•1xDown Vision™
•1xSideVision™
•1xRealVision™3D
R ange:
•CHIRPsonar=0.6M(2ft)to274m(900ft)
•DownVision™=0.6M(2ft)to183m(600ft)
•SideVision™=0.6M(2ft)to91m(300ft)
•RealVision™3D=0.6M(2ft)to91m(300ft)
8.3InternalGNSS(GPS/GL ONASS)receiverspecification
Channels:
Multiple—abilitytosimultaneouslytrackupto
28satellites
Coldstart:<2minutes
R eceiverICSensitivity:
•165dBm(Tracking)
•160dBm(Acquisition)
•148dBm(Coldstart)
GNSScompatibility:•GPS
•GL ONASS
•Beidou*
•Galileo*
SBA Scompatibility:•EGNOS
•GAGAN
•MSAS
•QZSS
•WAAS
T echnicalspecification
71

Raymarine AXIOM+ Series Specifications

General

Display Sizes	7", 9", 12", 16"
Display Type	IPS LCD
Touchscreen	Yes
Operating System	LightHouse 3
Waterproof Rating	IPX6/IPX7
RAM	4 GB
Internal Storage	16 GB
Radar Support	Yes
Chartplotter	Yes
Brightness	1500 nits
Processor	Quad-core
Connectivity	Wi-Fi, Bluetooth
GPS	Built-in GPS/GLONASS
Networking	NMEA 2000
Sonar	Supports CHIRP, RealVision 3D, SideScan, DownVision
Video Input	Yes
Operating Voltage	12/24 V DC
Display Resolution	7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
