Page #72 background image
Operatingfrequency:1574MHzto1605MHz
SignalAcquisition:
A
utomatic
AlmanacUpdate:A
utomatic
GeodeticDatum:
W
GS-84(alternativescanbeselectedonthe
MFD)
R
efreshRate:
10Hz(10timespersecond)
Antenna:
•Internal—Ceramicchipmountedneartopof
unit
P ositionAccuracy:
•WithoutSBAS:<=15metres95%ofthetime
•WithSBAS:<=5metres95%ofthetime
Note:
*Supportedinfuturesoftwareupdate .
72

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Raymarine AXIOM+ Series and is the answer not in the manual?

Raymarine AXIOM+ Series Specifications

General IconGeneral
Display Sizes7", 9", 12", 16"
Display TypeIPS LCD
TouchscreenYes
Operating SystemLightHouse 3
Waterproof RatingIPX6/IPX7
RAM4 GB
Internal Storage16 GB
Radar SupportYes
ChartplotterYes
Brightness1500 nits
ProcessorQuad-core
ConnectivityWi-Fi, Bluetooth
GPSBuilt-in GPS/GLONASS
NetworkingNMEA 2000
SonarSupports CHIRP, RealVision 3D, SideScan, DownVision
Video InputYes
Operating Voltage12/24 V DC
Display Resolution7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
