Raymarine AXIOM+ Series User Manual

Description
1
AdaptercablewithaR
ayNet(female)socketononeend,andawaterproof(female)
socketontheotherendacceptingthefollowingcableswithanRJ45Sea Talkhs®
waterprooflocking(male)plug:
•A62245(1.5m).
•A62246(15m).
2
AdaptercablewithaR
ayNet(female)socketononeend,andawaterproof(female)RJ45
socketontheotherend,alongwithalockingglandforawatertightfit.
3
AdaptercablewithaR ayNet(male)plugononeend,andanRJ45Sea Talkhs®waterproof
(male)plugontheotherend.
4
AdaptercablewithaR ayNet(male)plugononeend,andanRJ45SeaTalkhs®(male)
plugontheotherend.
5
AdaptercablewithaR ayNet(female)socketononeend,andanRJ45SeaTalkhs®
waterproof(male)plugontheotherend.
6
AdaptercablewithaR ayNet(female)socketononeend,andanRJ45SeaTalkhs®
(male)socketontheotherend.
Sparesandaccessories
77

Raymarine AXIOM+ Series Specifications

General

Display Sizes	7", 9", 12", 16"
Display Type	IPS LCD
Touchscreen	Yes
Operating System	LightHouse 3
Waterproof Rating	IPX6/IPX7
RAM	4 GB
Internal Storage	16 GB
Radar Support	Yes
Chartplotter	Yes
Brightness	1500 nits
Processor	Quad-core
Connectivity	Wi-Fi, Bluetooth
GPS	Built-in GPS/GLONASS
Networking	NMEA 2000
Sonar	Supports CHIRP, RealVision 3D, SideScan, DownVision
Video Input	Yes
Operating Voltage	12/24 V DC
Display Resolution	7" - 1024 x 600 (WVGA); 9" - 1280 x 720 (HD); 12" - 1280 x 800 (WXGA); 16" - 1920 x 1080 (Full HD)
