Raymarine Quantum User Manual

2.2Partssupplied
Thefollowingitemsaresuppliedwithyourproduct.
D13453-1
4
x4
1
2
3
ItemDescriptionQuantity
1
Quantum™Radome
1
2
10m(32.8ft)Powercable
1
3M8mountingboltswith
springwashersandat
washers
4
4Documentationpack
(includingmounting
template)
1
2.3Quantum™Radomeproduct
overview
TheQuantum™Radomeisacompact,solid-state
Radarscanner,utilizingCHIRPpulsecompression
forimprovedrangeresolution,andWi-Ficonnectivity
foreasierinstallation.Inconjunctionwitha
compatiblemultifunctiondisplay,theQuantum™
scannerprovidesamap-likerepresentationofthe
areaaroundyourvessel,enablingyoutoidentify
othervessels,buoys,andlandfeaturessuchas
coastlinesandhills.
D13399-1
TheQuantum™Radomehasthefollowingfeatures:
•Solid-statetechnology(nomagnetron)for
improvedefciency,andrapidstart-up.
•Rangeperformanceupto24nm(dependenton
installationlocation).
•CHIRPpulsecompressionforimprovedtarget
rangeresolution,andreducedbackgroundnoise.
•DataconnectionviaWi-Fi,orRaynetcable.
•RadarimagedisplayandcontrolviaRaymarine
multifunctiondisplay.
•24RPMscannerrotation.
•Lowpowerconsumption.
•12Vor24Voperation.
•WaterprooftoIPX6.
MultipleQuantum™Radarscanners
Only1(one)Quantum™Radarscannercanbeused
atanyonetime,pernetworkedsystem.
IfyouhavemorethanoneQuantum™Radar
scannerinstalledonyourvesselandwanttouse
thematthesametime,themultifunctiondisplays
towhichthescannersareconnectedmustNOT
benetworkedtogether.ThisappliestoQuantum™
scannersconnectedeitherwiredorwirelessly.
Documentandproductinformation
13

Raymarine Quantum Specifications

General

Radar Type	CHIRP Pulse Compression
Range	Up to 24 nautical miles
Antenna Size	18 inches
Power Consumption - Standby	7W
Beamwidth Horizontal	4.9°
Beamwidth Vertical	20°
Antenna Length	18 inches
Weight	5.6 kg (12.3 lbs)
Waterproof Rating	IPX6
Wireless Connectivity	Wi-Fi
Antenna Rotation Speed	24 RPM
Range Resolution	7.5 m
Target Tracking	MARPA (Mini Automatic Radar Plotting Aid)
Connectivity	Wi-Fi, Ethernet
Dimensions	210 mm x 180 mm
Compatibility	Raymarine MFDs
