Grounding
Ensurethatyouobservetheseparategrounding
adviceprovidedintheproduct’sdocumentation.
Moreinformation
Raymarinerecommendsthatbestpracticeis
observedinallvesselelectricalinstallations,as
detailedinthefollowingstandards:
•BMEACodeofPracticeforElectricaland
ElectronicInstallationsinBoats
•NMEA0400InstallationStandard
•ABYCE-11AC&DCElectricalSystemsonBoats
•ABYCA-31BatterychargersandInverters
•ABYCTE-4LightningProtection
Warning:Groundingnotrequired
Thisproductisfullyinsulatedanddoes
NOTrequireseparategrounding.
4.4Networkconnection
Thescannermustbeconnectedtoacompatible
Raymarinemultifunctiondisplay,eitherviaWi-Fi,
orviaaphysicalRayNetcableconnection.Once
connected,themultifunctiondisplaycanshowRadar
echodata.
Wired(RayNet)multifunctiondisplayconnection
Scannerconnectedtoamultifunctiondisplayusinga
RayNetcable.
D13408-2
12 / 24 V
1
2
3
ItemDescription
1
Quantum™Radome(forclarity,onlythe
connectionsareaoftheundersideoftheunitis
shownhere).
2
ConnectorpanelofcompatibleRaymarine
multifunctiondisplay.
3RayNetdatacable.
Wi-Fimultifunctiondisplayconnection
Scannerconnectedtoamultifunctiondisplayusing
Wi-Fi.
1
2
3
12 / 24 V
D13410-2
ItemDescription
1
CompatibleRaymarinemultifunctiondisplaywith
Wi-Ficapability.
2
Quantum™Radome.
3Wi-Fidatalink.
RefertotheSwitchonandinitialsetupsection,and
toyourMFDdocumentationforfurtherinformation
aboutsettinguptheWi-Ficonnectionbetweenyour
MFDandtheQuantum™scanner.
Cablesandconnections
27

Raymarine Quantum Specifications

General

Radar Type	CHIRP Pulse Compression
Range	Up to 24 nautical miles
Antenna Size	18 inches
Power Consumption - Standby	7W
Beamwidth Horizontal	4.9°
Beamwidth Vertical	20°
Antenna Length	18 inches
Weight	5.6 kg (12.3 lbs)
Waterproof Rating	IPX6
Wireless Connectivity	Wi-Fi
Antenna Rotation Speed	24 RPM
Range Resolution	7.5 m
Target Tracking	MARPA (Mini Automatic Radar Plotting Aid)
Connectivity	Wi-Fi, Ethernet
Dimensions	210 mm x 180 mm
Compatibility	Raymarine MFDs
