Raymarine Quantum User Manual

10.1Quantum™Radaraccessories
Thefollowingaccessoriesareavailableforthe
Quantum™Radarscanner:
Accessories
ItemPartnumber
10m(32.8ft.)Quantum™
powercable
A80309
5m(16.4ft.)Quantum™
datacable
A80274
10m(32.8ft.)Quantum™
datacable
A80275
15m(49.2ft.)Quantum™
datacable
A80310
25m(82.0ft.)Quantum™
datacable
A80311
Quantum™Y-adaptercable
A80308
RayNetcablejoinerA80162
10.2Networkhardware
Item
Part
num-
berNotes
HS5RayNet
networkswitch
A80007
5–portswitchfornetwork
connectionofmultiple
devicesfeaturingRayNet
connectors.Equipmentwith
RJ45SeaTalk
hs
connectors
canalsobeconnectedusing
suitableadaptercables.
RJ45SeaTalk
hs
networkswitch
E55058
8–portswitchfornetwork
connectionofmultiple
SeaTalk
hs
devicesfeaturing
RJ45connectors.
RJ45SeaTalk
hs
crossovercoupler
E55060•Enablesdirectconnection
ofRJ45SeaTalk
hs
devices
tosmallersystemswhere
aswitchisnotrequired.
•Enablestheconnectionof
RJ45SeaTalk
hs
devices
toaHS5RayNetnetwork
switch(inconjunctionwith
suitableadaptercables).
•Enables2RJ45SeaTalk
hs
cablestobeconnected
togethertoextendthe
lengthofthecabling.
Recommendedforinternal
installations.
Important:DoNOTuse
crossoverdevicesforPOE
(PowerOverEthernet)
connections.
EthernetRJ45
coupler
R32142•Enablesdirectconnection
ofRJ45SeaTalk
hs
devices
tosmallersystemswhere
aswitchisnotrequired.
•Enablestheconnectionof
RJ45SeaTalk
hs
devices
toaHS5RayNetnetwork
switch(inconjunctionwith
suitableadaptercables).
•Enables2RJ45SeaTalk
hs
cablestobeconnected
togethertoextendthe
lengthofthecabling.
Recommendedforexternal
installations.
46
QuantumRadome

Raymarine Quantum Specifications

General

Radar Type	CHIRP Pulse Compression
Range	Up to 24 nautical miles
Antenna Size	18 inches
Power Consumption - Standby	7W
Beamwidth Horizontal	4.9°
Beamwidth Vertical	20°
Antenna Length	18 inches
Weight	5.6 kg (12.3 lbs)
Waterproof Rating	IPX6
Wireless Connectivity	Wi-Fi
Antenna Rotation Speed	24 RPM
Range Resolution	7.5 m
Target Tracking	MARPA (Mini Automatic Radar Plotting Aid)
Connectivity	Wi-Fi, Ethernet
Dimensions	210 mm x 180 mm
Compatibility	Raymarine MFDs
