Raymarine Quantum - Location Requirements

Example:expandedsystem(powercablesnot
shown)
00
SeaTalk
ng
D13407-1
SeaTalk
ng
RayNet
1
3
4
5
6
7
9 10
2
2
8
RayNet
11
ItemDescription
1
Sonarmodule
2RayNetcables
3RayNetnetworkswitch
4
Quantum™Radome
5
Multifunctiondisplay
6DownVisiontransducer
7
EvolutionACU
8
SeaTalk
ng
spurcable
9EvolutionEV
10Pilotheadcontroller
11Wi-Fidatalink
3.7Locationrequirements
TheoptimumheightfortheQuantum™scanneris
alocationthatishighenoughabovethewaterline
togivealongrangeline-of-sighttothehorizon,but
notsohighastobeadverselyaffectedbytheboat's
pitchingandrolling.
D11700-1
Thescannermustalsobemountedwhereitis:
•Aboveheadheight.
•Easilyaccessible.
•Asnearaspossibletotheboat'scenterline.
•Onarigidandstableplatform,capableofsecurely
supportingthescannerunderseagoingconditions.
•Clearoflargeobjectssuchastheybridge,large
enginestacks,searchlights,horns,mastsetc.
(seeShadowareasandfalseechoesforadditional
information)
•Clearofheatandfumes.
•Atleast1m(3ft)fromamagneticcompassor
otherscanners.
Shadowareasandfalseechoes
MounttheRadarscannerawayfromlargestructures
orequipment,suchasenginestacks,searchlights,
horns,ormasts.Theseobjectsmaycauseshadow
areasandfalseechoes.Forexample,ifyou
mounttheRadarscanneronamast,echoesfrom
othertargetsmaybereectedfromthemast.Wet
sailsmayalsocauseshadowareas,soRadar
performancemaybereducedintherain.Itis
particularlyimportanttoavoidshadowareasnearthe
bow.RaisingorevenloweringtheRadarscanner
mayhelptoreducetheseeffects.
Inshadowareasbeyondtheobstructiontherewillbe
areductionofthebeamintensity.Theremaybea
blindsectorifthebeamintensityisnotsufcientto
obtainanechofromanobject.Thismayoccureven
atcloserange.Forthisreasontheangularwidth
andrelativebearingofanyshadowareamustbe
determinedatinstallation.
Youmaybeabletodetectshadowareasorfalse
echoesonyourmultifunctiondisplay.Forexample,
seacluttercanbeusedasagoodindicatorofblind
arcs.DarksectorsontheRadardisplayindicate
Planningtheinstallation
19
