Multiplemultifunctiondisplayconguration
ARaymarinenetworkswitchcanbeusedtoconnect
theunittomorethan1multifunctiondisplay.
3
54
2 2
1
12 / 24 V
2
D13409-2
ItemDescription
1
Quantum™radome(forclarity,onlythe
connectionsareaoftheundersideoftheunitis
shownhere).
2RayNetcable.
3RayNetnetworkswitch.
4
ConnectorpanelofcompatibleRaymarine
multifunctiondisplay.
5
Connectorpanelofadditionalcompatible
Raymarinemultifunctiondisplay.
Fordetailsonavailablenetworkhardwareand
cablesrefertoChapter10Sparesandaccessories.
28
QuantumRadome
