Usinganexistingcombinedpower/datacable
fromanolderRaymarineDigitalRadar
D13456-1
12 / 24 V
RayNet
3
4
A80308
1
2
Note:TheY-adaptercableisactuallywhite.For
clarity,itisshownintheabovedrawingindifferent
colors.
1.RayNetdataconnection.Thiscableispartof
theA80308Y-adapteraccessorycable.
2.12V/24Vpowerconnection.Thiscableispart
oftheA80308Y-adapteraccessorycable.
3.A80308Y-adapteraccessorycable(notsupplied
withthescanner).
4.ExistingcombinedDigitalRadarpower/data
cable.
Cablerouting—polemount
Thereare2typicalcableroutingscenariosforpole
mountinstallations.
•Usingseparatepoweranddatacables.
•Usinganexistingcombinedpower/datacable
fromanolderRaymarineDigitalRadarscanner.In
thisscenario,theA80308Y-adapteraccessoryis
required(notsuppliedwiththescanner).
Usingseparatepoweranddatacables
Note:Theroutingoptionsdescribedandillustrated
inthissectionassumethataphysicaldata
connectionisusedbetweenyourRadarscanner
andmultifunctiondisplay(MFD).However,ifthe
scannerisconnectedtoyourMFDviaWi-Fi,a
physicalRayNetconnectionisnotrequired.
Thefollowingdrawingillustratesthecableroutingfor
ascannermountedonaplatform,usingseparate
cablesforthepoweranddataconnection.
D13455-1
2
12 / 24 V
1
RayNet
1.RayNetdataconnection.
2.12V/24Vpowerconnection.
Note:
•Aseparatepowercableissuppliedwithall
Quantum™Radarvariants.
•NotallQuantum™radarvariantsaresupplied
withaRayNetcable.RefertotheChapter2
Documentandproductinformationsectionfor
moreinformation.
•Refertothe10.4RayNettoRayNetcablesand
connectorssectionforinformationonsuitable
accessoryRayNetcables.
Usinganexistingcombinedpower/datacable
fromanolderRaymarineDigitalRadar
D13457-1
12 / 24 V
RayNet
A80308
1
2
3
4
Note:TheY-adaptercableisactuallywhite.For
clarity,itisshownintheabovedrawingindifferent
colors.
24
QuantumRadome
