Raymarine RV-100 User Manual

2.
1Documentinformation
Thisdocumentcontainsimportantinformationrelatedtotheinstallationof
yourRaymarine®product.
Thedocumentincludesinformationtohelpyou:
•Planyourinstallationandensureyouhaveallthenecessaryequipment.
•Installandconnectyourproductaspartofawidersystemofconnected
marineelectronics.
•Troubleshootproblemsandobtaintechnicalsupportifrequired.
ThisandotherRaymarine®productdocumentsareavailabletodownload
inPDFformatfromwww.raymarine.com/manuals
Applicableproducts
Thisdocumentisapplicabletothefollowingproducts:
RV–100RealVision™3DTransomMountTransducer
•A 80464—RV-100RealVision™3DTransomMountTransducer(Plastic).
•TheRV-100isaRealVision™3Dtransducer,capableofproducing3Dsonar
images.
•ThetransducercanbeconnectedtoRealVision™3DorRealVision™3DMax
variantMFDsrunningLightHouse™3orLightHouse™4software.
Note:
Additionalmountingoptionsareavailableforthetransducer
,including:
•PartnumberA80479:RealVision™3DTransducerStepMount
•PartnumberA80480:RealVision™3DTransducerJackPlateMount
•PartnumberA80482:RealVision™3DTransducerJackPlateSpacerKit
Forfurthermountinginformation,refertothedocumentationsuppliedwith
theseproducts.
Documentillustrations
Yourproductandifapplicable,itsuserinterfacemaydifferslightlyfromthat
shownintheillustrationsinthisdocument,dependingonproductvariantand
dateofmanufacture.
Allimagesareprovidedforillustrationpurposesonly.
2.2Productoverview
TheRV-100isatransom-mountedRealVision™3Dsonartransducercapable
ofproducingrealistic3Drepresentationsoftheobjectsbelowyourvessel,to
helpyouidentifyunderwaterstructuresandlocatefish.
•4sonarchannels:DownVision™,SideVision™,CHIRP,andRealVision™3D
sonartechnologycombinedinasingleunit.
Documentandproductinformation
11

Raymarine RV-100 Specifications

General

Brand	Raymarine
Model	RV-100
Category	Transducer
Language	English
