Raymarine RV-100 User Manual

Item
Description
9M10serratednylocknut
10
T
ransducer(includingfitted8m/26.2ftcable)
3.3R
equiredadditionalcomponents
Thisproductformspartofasystemofelectronicsandrequiresthefollowing
additionalcomponentsforfulloperation.
•ForalistofRealVision™3Dsonar-capabledevices,referto:Compatible
RealVision™3Dproducts
•Forlongercableruns,atransducerextensioncablewillalsoberequired.
Foralistofsuitablecables,referto:Chapter10Sparesandaccessories
CompatibleRealVision™3Dproducts
ThetransducermustbeconnectedtoaRealVision™3Dsonar-capable
device.ThefollowingRealVision™andRealVision™Max3Dsonar-capable
productsarecompatiblewiththetransducer.
1.RVX1000externalRealVision™3Dsonarmodule(aLightHouse™3or
LightHouse™4compatibleMFDisalsorequired).
2.LightHouse™3orLightHouse™4compatibleMFDwithbuiltinRealVision™
3Dsonarmodule(i.e.:Axiom,Axiom+orAxiomProMFDs).
3.RVM1600externalRealVision™3DMaxsonarmodule(aLightHouse™4
compatibleMFDisalsorequired).
4.LightHouse™4compatibleMFDwithbuiltinRealVision™3DMaxsonar
module(i.e.:Axiom2ProRVMMFDs).
Planningtheinstallation
15

Raymarine RV-100 Specifications

General

Brand	Raymarine
Model	RV-100
Category	Transducer
Language	English
