3.
1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1.Planyoursystem.
2.Obtainallrequiredequipmentandtools.
3.Siteallequipment.
4.Routeallcables.
5.Drillcableandmountingholes.
6.Makeallconnectionsintoequipment.
7.Secureallequipmentinplace.
8.Poweronandtestthesystem.
Schematicdiagram
Aschematicdiagramisanessentialpartofplanninganyinstallation.Itisalso
usefulforanyfutureadditionsormaintenanceofthesystem.Thediagram
shouldinclude:
•Locationofallcomponents.
•Connectors,cabletypes,routesandlengths.
Warningsandcautions
Important:
Beforeproceeding,ensurethatyouhavereadandunderstoodthe
warningsandcautionsprovidedinthefollowingsectionofthisdocument:
p .7—Importantinformation
3.2P artssupplied
Thefollowingpartsaresuppliedinthebox.
Unpackyourproductcarefullytopreventdamageorlossofparts.Checkthe
boxcontentsagainstthelistbelow.Retainthepackaginganddocumentation
forfuturereference.
Item
Description
1Escutcheonplate
25xCableclips
3
9xSelftapperscrew(3.9x13)(4xforescutcheonand5xfor
cableclips)
4
3xSelftapperscrew(4.2x18)(fortransducermountingbracket
installation)
5Transducermountingbracket
6Cableconnectorkit,consistingof:
•ORing
•Splitringx2(1xspare)
•L
ockingcollar
•Splitringfittingtool
7Documentationpack
8M10x65serratedbolt
14
