RayTek MARATHON MM SERIES - Fixed Focus

Technical Data
Marathon MM Rev. D7 Jul 2017 17
3.2.2 Fixed Focus
Optical Resolution D:S
LT, MT, G5, 3M 70:1
G7 100:1
Available Optics
LT, MT, G5, 3M, G7 SF1, SF2, SF3
LT, 3M CF1
The focus distance is measured from the front end of the sensor. For units with
Air/Water Cooled Housing you have to subtract 34.5 mm (1.358 in) from the focus
distance. This is very important especially for sensors with close focus optic!
