Operation
48 Rev. D7 Jul 2017 Marathon MM
7.5 Factory Defaults
The following table provides the values in case of a factory default. The factory default can only be
initiated by using the DataTemp Multidrop Software. The Multidrop address and the baud rate will not
change from the last value when factory default is done.
Parameter
Factory defaults
Display mode
°C, TEMP- Display
Emissivity
0.95
Transmission
1.00
Focus
600 mm (23.6 in.)
Laser
Off
Average
000.0 (off)
Peak Hold
000.0 (off)
Valley Hold
000.0 (off)
Low mA (4 mA)
Minimum temperature of range
High mA (20 mA)
Maximum temperature of range
Multidrop Address
not changed (0 with delivery)
Baud Rate
not changed (38400 with delivery)
Temperature Unit
°C
Relay alarm output
controlled by unit
Current Output
4 – 20 mA
Control Panel
unlocked
Serial Communication
4-wire
RS485 Transfer Mode
Poll mode
Output String (RS485)
UTEIEC = temperature unit, target temperature,
emissivity, internal temperature, error code
Figure 27: Factory Defaults
