Operation
Marathon MM Rev. D7 Jul 2017 41
Figure 21: Advanced Peak Hold
For the advanced peak hold function, there are the same settings for reset and signal slope available like
for the peak hold function, see sections 7.3.2.1 Reset, page 38 and 7.3.2.2 Signal Slope, page 39.
7.3.4 Valley Hold
This function works similar to the peak hold function, except it will search the signal for a minimum.
7.3.5 Advanced Valley Hold
This function works similar to the advanced peak hold function, except it will search the signal for a
local minimum.
