Description
Char
Format
P
B
S
N
legal values
factory
default
LCD
Char
Error code
EC
nnnn


hex value of ErrCode:
BIT0 Object temp. over range
BIT1 Object temp. under range
BIT2 Internal temp. over range
BIT3 Internal temp. under range
BIT4 ADC initialisation error
BIT5 EEPROM error user space
BIT6 EEPROM error calibration
BIT7 Device in init phase
BIT8 Focus motor error
BIT9 Focus zero position lost
BITA Focus motor moving
BITB mA output over range
BITC mA output under range
Emissivity source
ES
X


I = Emissivity from Internal (by
command)
E = Emissivity from External
analog input (0V—5V)
I
Valley hold time
F
Nnn.n




0.0 - 299.9s (300 = )
0.0s
V
Focal distance
FC
nnn.n



within the focus range, in meter
Time out: 1000 ms (Polling)
Time out: 2000 ms (Setting)
0.6
F
Activate pre-calculation
Filter
FF
n 0 0


0 = off
1 = Filter Average
2 = Filter Detector
1
Average time
G
nnn.n




0.0 – 999.0 s
0.0 s
A
Top of mA range
H
nnnn.n




H
RS485 mode
HM
n



2 = 2-wire, 4 = 4-wire
4
COM
Sensor internal temp.
I
nnn.n


in current scale (C/F)
Switch panel lock
J
X



L = locked
U = unlocked
unlocked
CP
Relay alarm output control
K
n


0 = off 1 = on
2 = Target and Internal
norm. open
3 = Target and Internal
norm. closed
4 = Internal, normal open
5 = Internal, norm. closed
6 = Target, norm. open
7 = Target, norm. closed
2
Bottom of mA range
L
nnnn.n




L
Output current
O
nn.nn


0.00 – 20.00 current in mA
21 = over range; 60 = controlled
by unit
60
After reset =
60
Peak hold time
P
nnn.n




0.0 - 299.9 s (300 = )
0.0 s
P
AD counts
Q
nnnnnnn


Reset
RS

Reset of the firmware,
acknowledged with:
!RS[CR][LF]
#XI1[CR][LF]
Time out: 12000 ms
Temperature range
RT


E = Extended range
S = Standard range
(= <bottomTemp> <topTemp>)
S
-
