Chapter 2
Intelligent Field Panel
Integra32
™
Hardware Guide RBH Access Technologies Inc.
6
Off
Off
On
On
Off
12
On
Off
On
On
Off
13
Off
On
On
On
Off
14
On
On
On
On
Off
15
Off
Off
Off
Off
On
16
Direct Connect/Modem Selection
DIP switch 8 specifies whether the IRC-2000 is connected directly to a serial port on the
PC or communicates with the PC over a modem. Contact the RBH tech support office
for information on the optional TCP/IP Ethernet connection.
Direct Connect / Modem Selection
DIP Switch 8
Interface Type
OFF
Direct Connect To PC
ON
Modem
DIP switch 8 specifically turns on the password requirement and enables modem call-
back. The panel will still answer a modem call with DIP switch 8 off. You should
initially set up the panel with DIP switch 8 off, program the panel and download to it.
Then turn DIP switch 8 on to enable password checking.
Computer/Modem Port Baud Rate Selection
The controller's serial port baud rate is set with controller DIP switches 6 and 7. This
setting determines the speed used to communicate with the modem or PC serial port. If
the controller is connected directly to the PC, the controller baud rate must be the same
as the baud rate set for the port on the PC. The default PC baud rate is 38,400.
Controller Baud Rate Selection
DIP Switch 6
DIP Switch 7
Baud Rate
OFF
OFF
9,600
ON
OFF
28,800
OFF
ON
38,400
ON
ON
56,000
