Chapter 2
Intelligent Field Panel
Integra32
Hardware Guide RBH Access Technologies Inc.
22
RS485 Interfaces
Connect the PC-100 to IRC-2000 & URC-2000 panels through an RS485 connection,
and connect the PC-100 to an Alarm Panel through an RS485 connection.
Status LED's
Health
The green health LED indicates synchronization with the LSCP bus and the red health
LED indicates LSCP problems. For normal operation the green led will be flashing
quickly and brightly and the red led will be mostly off.
PC Interface
The PC Interface port has two LEDs to show the flow of data between the PC-100 and
the PC. The red RX LED (LED9) flashes when the controller receives data. The green
TX LED (LED10) flashes when the controller transmits data.
Access Panel Interface
The Access Panel Interface is an RS485 port that has two LEDs to show the flow of data
between the PC-100 and IRC2000 and/or URC2000 panels. The red RX LED (LED5)
flashes when the controller receives data. The green TX LED (LED6) flashes when the
controller transmits data.
Alarm Panel Interface
The Alarm Panel Interface is an RS485 port that has two LEDs to show the flow of data
between the PC-100 and a Bosch or a Summit panel. The red RX LED (LED7) flashes
when the controller receives data. The green TX LED (LED8) flashes when the
controller transmits data.
Jumpers
JP1 Do not use (for developmental purposes only).
JP2 & JP3 Both jumpers are left in the upper position for normal operation. This will
connect the PC Interface port to the micro controller. Move the jumper to
the lower position only if a LAN interface module is attached to the PC100.
This will connect the PC Interface port to the LAN interface module for the
purpose of programming it.
