Specifications
Integra32
™
Hardware Guide RBH Access Technologies Inc.
36
I R C - 2000 S p e c i f i c a t i o n
Controller Power Requirements: 9 – 14V DC
Current Consumption: 250ma
Flash ROM: Download firmware upgrades from the PC to IRC-2000
System Capacities: IRC-2000’s per System Maximum of 32
Readers per IRC-2000 2
Cardholder (normal) Maximum 5,000
(extended) Maximum 8,000
Event Log per IRC-2000 Maximum 1,400
Network Connection: Type RS-232 or RS-485
Serial Port Speed 9600, 28800, 38400, or 56000
Real Time Clock: Dallas DS1994 with battery back up
Housing dimensions: H 12in. x W 14in. x D 3½in.
Operating temperature: 0 to 70C (35 - 150F)
Operating Humidity: 20 to 80% RH (non-condensing)
PC Connection: Can be connected via RS232, RS485, or by Modem
