Chapter 2
Intelligent Field Panel
Integra32
™
Hardware Guide RBH Access Technologies Inc.
16
On
Off
On
Off
Off
5
Off
On
On
Off
Off
6
On
On
On
Off
Off
7
Off
Off
Off
On
Off
8
On
Off
Off
On
Off
9
Off
On
Off
On
Off
10
On
On
Off
On
Off
11
Off
Off
On
On
Off
12
On
Off
On
On
Off
13
Off
On
On
On
Off
14
On
On
On
On
Off
15
Off
Off
Off
Off
On
16
Computer Port Baud Rate Selection
The controller's RS485 port baud rate is set with DIP switches 6 and 7. This setting
determines the speed used to communicate with the PC. All controllers connected to the
software through the same port must have the same baud rate. The default PC baud rate
is 38,400.
Controller Baud Rate Selection
DIP Switch 6
DIP Switch 7
Baud Rate
OFF
OFF
9,600
ON
OFF
28,800
OFF
ON
38,400
ON
ON
56,000
PC Connections
RS485 Connection
The URC-2000 controller supports a two-wire RS485 interface. The RS485 interface
allows the distance between the controller and the PC to be up to 4000 feet (1200
meters). RS485 requires one twisted pair shielded cable.
