Specifications
Integra32
™
Hardware Guide RBH Access Technologies Inc.
38
PC- 100 S p e c i f i c a t i o n
Controller Power Requirements: 9 – 14V DC
Current Consumption: 150ma
Flash ROM: Download firmware upgrades from the PC to PC-100.
System Capacities: PC-100’s per System Maximum of 1
Network Connection: Type RS-232 and RS-485
Serial Port Speed 9600, 28800, 38400, or 56000
Real Time Clock: Dallas DS1994 with battery back up
Board dimensions: H 4¼in. x W 4¾in.
Operating temperature: 0 to 70C (35 - 150F)
Operating Humidity: 20 to 80% RH (non-condensing)
PC Connection: Can be connected via RS232, RS485, or by Modem
