MAINTENANCE AND CONTROL PROGRAMME
!
ATTENTION!
U
TILISE SPECIALISED PERSONNEL OR SEE AN AUTHORISED SERVICE SHOP FOR ANY TYPES OF MAINTENANCE, REVISION OR
REPAIRS.
PROGRAMME
TO BE PERFORMED EVERY….HOURS…
8 40 150 500
1 CHECK BATTERY LIQUID X
2 CHECK WEARING OF SUCTION MOTOR CARBON BRUSHES X
3 CHECK WEARING OF BRUSH MOTOR CARBON BRUSHES X
4 CLEAN FILTER AND RECOVERY TANK X
5 REMOVE IMPURITIES FROM THE DRAINAGE TUBE X
6
CHECK WEARING OF SQUEEGEE BLADES, CONTACT EDGING MUST BE
WHOLE; OTHERWISE REPLACE
X
7 CHECK BRUSH WEARING X
8 SREPLACE BRUSH X
TROUBLESHOOTING
DEFECT CAUSE REMEDY
THE MACHINE DOES NOT SWITCH ON LOW BATTERY CHARGE CHECK CHARGE STATUS AND RECHARGE IF NECESSARY
BATTERIES ARE NOT CONNECTED CONNECT BATTERIES (AS PER BATTERY CONNECTION FIGURE)
230V.AC CABLE IS DISCONNECTED
(FOR AC-POWERED MACHINES)
CONNECT CABLE TO THE ELECTRICAL NETWORK.
3A ELECTRONIC CONTROL FUSE BLOWN CHECK AND REPLACE IF NECESSARY (FIG.3 - POS.5)
THE START-UP SWITCH KEY HAS NOT BEEN TURNED TO
POSITION “1”
TURN THE KEY TO SAID POSITION
THE SQUEEGEE DOES NOT ENTIRELY DRY THE FLOOR. THE SQUEEGEE DRAINAGE TUBE IS DISCONNECTED RECONNECT TUBE
S
UCTION TUBE CLOGGED DISMANTLE AND CLEAN TUBE
DEBRIS IS CAUGHT IN THE SQUEEGEE REMOVE DEBRIS
SUCTION LOSS FIX LEAK
TUBE AND SUCTION MOTOR GASKETS LOCATED UN-
DER THE RECOVERY TANK ARE DAMAGED
REPLACE GASKET/S
S
QUEEGEE BLADES WORN TURN OR REPLACE BLADES
THE WASHER-DRYER SPRAYS WATER IN RELATE TO
THE JOINT SPACE BETWEEN TILES.
S
QUEEGEE HAS NOT BEEN ASSEMBLED AND REGU-
LATED CORRECTLY
P
ROPERLY ASSEMBLE AND REGULATE SQUEEGEE
(
SEE “WASHER-DRIER PREPARATION – SQUEEGEE
ASSEMBLY AND/OR REGULATION”)
THE CLEANING SOLUTION DOES NOT COME DOWN OR
ONLY A SMALL AMOUNT COMES DOWN ON THE BRUSHES.
BRUSH WATER HOSE CLOGGED CLEAN TUBE
ELECTROVALVE DAMAGED OR DIRTY CLEAN AND/OR REPLACE ELECTROVALVE
FILTER CLOGGED OR FAULTY CLEAN OR REPLACE FILTER
T
HE MACHINE IS NOT CLEANING WELL.BRUSH WORN REPLACE
CLEANING SOLUTION UNSUITABLE REPLACE CLEANING SOLUTION
BRUSH NOT SUITABLE FOR FLOOR TYPE USE SUITABLE BRUSHES
E
LEVATED WORK SPEED SLACKEN
THE SUCTION MOTOR DOES NOT SWITCH ON. BATTERIES NOT CONNECTED CONNECT BATTERIES
SUCTION MOTOR CARBON BRUSHES WORN CHECK AND/OR REPLACE
SUCTION MOTOR DISCONNECTED OR DAMAGED CHECK CONNECTION OR REPLACE MOTOR
FUSE BLOWN CHECK AND/OR REPLACE
THE BRUSH DOES NOT ROTATE. BATTERIES NOT CONNECTED CONNECT BATTERIES
MOTOR CARBON BRUSHES WORN CHECK AND/OR REPLACE
M
OTOR DISCONNECTED OR DAMAGED CHECK CONNECTION OR REPLACE MOTOR
