70
Cargador - CBHF1-SM 24V 12A confi gurción dip switch “ fi g.11/A.
Las siguientes tablas muestran todas las confi guraciones de los dipswitch para la programación del cargador de batería CBHF1-SM 24V 12A.
DIP 8 VB
ON
12
OFF
24
DIP 1 DIP 2 DIP 3 DIP 4 CURVA DE CARGA
ON ON ON ON 0
►OFF ON ON ON 1 (Curva para baterías tracción de PLOMO-ÁCIDO [con líquido].)
ON OFF ON ON 2
OFF OFF ON ON 3
ON ON OFF ON 4
OFF ON OFF ON 5
►ON OFF OFF ON 6 (Curva para baterías AGM y GEL y otras constructores).
OFF OFF OFF ON 7
ON ON ON OFF 8
OFF ON ON OFF 9
ON OFF ON OFF 10
►OFF OFF ON OFF 11 (Curva para baterías de GEL tipo SONNENSCHEIN, DETA y otras constructores).
ON ON OFF OFF 12
OFF ON OFF OFF 13
ON OFF OFF OFF 14
OFF OFF OFF OFF 15
DIP 5 DIP 6 DIP 7 CORRIENTE
ON ON ON
4A
OFF ON ON
8A
ON OFF ON
10A
OFF OFF ON
12A
DIP 5, DIP 6, DIP 7, con CURVA DE CARGA 11 seleccionada.
DIP 8, para la selección del
voltaje de la batería.
DIP 1, DIP 2, DIP 3, DIP 4 para la selección de la CURVA DE CARGA
DIP 1 DIP 2 DIP 3 DIP 4 COURBE DE CHARGE
ON ON ON ON 0
►OFF ON ON ON 1 (Courbe pour batteries de traction type PLOMB-ACIDE [avec liquide]).
ON OFF ON ON 2
OFF OFF ON ON 3
ON ON OFF ON 4
OFF ON OFF ON 5
►ON OFF OFF ON 6 (Courbe pour batteries AGM et GEL et d’autres fabricants).
OFF OFF OFF ON 7
ON ON ON OFF 8
OFF ON ON OFF 9
ON OFF ON OFF 10
►OFF OFF ON OFF 11 (Courbe pour batteries type GEL, SONNENSCHEIN, DETA et d’autres fabricants).
ON ON OFF OFF 12
OFF ON OFF OFF 13
ON OFF OFF OFF 14
OFF OFF OFF OFF 15
Chargeur - CBHF1-SM 24V 12A confi guration dip switch “ fi g.11/A.
Sur les tables suivantes sont indiquées toutes les confi gurations des “dipswitch” pour la programmation du chargeur CBHF1-SM 24V 12A.
DIP 5 DIP 6 DIP 7 CURRENT
ON ON ON
4A
OFF ON ON
8A
ON OFF ON
10A
OFF OFF ON
12A
DIP 8 VB
ON
12
OFF
24
DIP 5, DIP 6, DIP 7 pour la selection du COURANT 11.
DIP 8, pour la selection de
la tension des batteries.
DIP 1, DIP 2, DIP 3, DIP 4 pour sélectionner la COURBE DE CHARGE.
