71
Ladegerät - CBHF1-SM 24V 12A Dip-Switch Konfi guration “ Fig.11/A.
Die folgenden Tabellen Laufdeck alle Einstellungen der “dipswitch” für die Programmierung des Ladegerätes CBHF1-SM 24V 12A.
DIP 8 VB
ON
12
OFF 24
DIP 1 DIP 2 DIP 3 DIP 4 LADEKURVE
ON ON ON ON 0
►OFF ON ON ON 1 (Ladekurve für traktion BLEI-SÄURE-Batterien [mit fl üssigem]).
ON OFF ON ON 2
OFF OFF ON ON 3
ON ON OFF ON 4
OFF ON OFF ON 5
►ON OFF OFF ON 6 (
Ladekurve für AGM und GEL- (versiegelte) Batterien typ und anderen Herstellern.).
OFF OFF OFF ON 7
ON ON ON OFF 8
OFF ON ON OFF 9
ON OFF ON OFF 10
►OFF OFF ON OFF 11 (Ladekurve für GEL-Batterien typ SONNENSCHEIN, DETA und anderen Herstellern.).
ON ON OFF OFF 12
OFF ON OFF OFF 13
ON OFF OFF OFF 14
OFF OFF OFF OFF 15
DIP 5 DIP 6 DIP 7 STROM
ON ON ON 4A
OFF ON ON 8A
ON OFF ON 10A
OFF OFF ON 12A
DIP 5, DIP 6, DIP 7 mit LADEKURVE 11 geselecteerde.
DIP 8, für die Auswahl der
Batteriespannung
.
DIP 1, DIP 2, DIP 3, DIP 4 für die Auswahl der LADEKURVE.
DIP 1 DIP 2 DIP 3 DIP 4 OPLADNINGSKURVE
ON ON ON ON 0
►OFF ON ON ON 1 (Kurve for BLY-SYRE batterier [med væske]).
ON OFF ON ON 2
OFF OFF ON ON 3
ON ON OFF ON 4
OFF ON OFF ON 5
►ON OFF OFF ON 6 (Kurve for AGM OG GELE batterier (forseglede) og andre fabrikanter).
OFF OFF OFF ON 7
ON ON ON OFF 8
OFF ON ON OFF 9
ON OFF ON OFF 10
►OFF OFF ON OFF 11 (Kurve for GELE batterier af typen SONNENSCHEIN, DETA og andre fabrikanter).
ON ON OFF OFF 12
OFF ON OFF OFF 13
ON OFF OFF OFF 14
OFF OFF OFF OFF 15
Batterilader - CBHF1-SM 24V 12A dip switch konfi guration “ fi g.11/A.
I de følgende tabellerne gengives alle dipswitch indstillingerne for programmering af batteriladeren CBHF1-SM 24V 12A.
DIP 5 DIP 6 DIP 7 STRØM
ON ON ON 4A
OFF ON ON 8A
ON OFF ON 10A
OFF OFF ON 12A
DIP 8 VB
ON
12
OFF 24
DIP 5, DIP 6, DIP 7 med OPLADNINGSKURVE 11 valgt.
DIP 8, for valg
af batterispænding.
DIP 1, DIP 2, DIP 3, DIP 4 for valg af OPLADNINGSKURVEN.
