Note: 3D CAD ﬁles for our manipulators are available upon request to assist with integration.

4 INTERFACING AND INTEGRATION

4.1 BRAVO 5 / BRAVO 7

4.1.1 Mechanical

• MANIPULATOR BASE INTEGRATION

• CONNECTOR CLEARANCE

92mm

56mm

88mm

44mm

8mm

68mm

51mm

43.5mm

28mm

23mm

REAR

4 X 6.80 19.75

M8X1.25 - 6H 16

220mm

45mm

19mm

Bend Radius: 90mm 32.5mm
