4.2 BRAVO 2 / BRAVO 3
4.2.1 Mechanical
• MANIPULATOR BASE INTEGRATION
Option 1 – Reach Bravo Mounting Kit
Option 2 – Direct Backplate Integration
Bravo 2 and 3 Mounting Kit Technical Drawings
Bravo 2 and 3 Mounting Kit Technical Drawings
45mm
10mm
90mm
25mm
110mm
139mm
11.4
11.4
21
56
21
86mm
82mm
62mm
R65
37.5mm
37.5mm
74 x 4mm
ACME Thread
M8X1.25 - 6H 8
5 X 6.80 10
