Any additional rectification work required will be assessed and quoted during the servicing process.
Reach Robotics’s Support Program provides you with the technical support you require to get your project up-and-running
quickly. With three-tiered Support Plans, After-Sales Care, and Priority Servicing, rest assured that your manipulator needs are
covered – even in the trickiest of times.
8 REACH ROBOTICS SUPPORT PROGRAM
The Reach Bravo system is recommended for an OEM Servicing every one (1) year or 200 operational hours, whichever occurs
first. Reach Robotics oer a Capped Price Service with each new Reach Bravo system. The coverage period of the Capped
Price Service program is for a period of two (2) years, or 200 operational hours, whichever occurs first. For details on the
Reach Robotics Service Program please contact Reach Robotics.
7 RECOMMENDED SERVICING SCHEDULE
7.1 BRAVO SERVICING OVERVIEW
System Item Procedure Description
Subassembly GND Black
Mechanical O-rings Replace
Gears Clean and re-lubricate
Keyway systems Check backlash and tune
Crimps, connectors, and wire harness Visually Inspect
Internal Fasteners Replace and apply Loctite
Motors Check output torque
Subassembly ETH RX- Orange
Electrical Electrical Board Check indicators and functionality
Encoders Visually Inspect and recalibrate if required.
Encoder boards Check indicators and functionality
Subassembly GND Black
Software Software Revision Upgrade to latest software
Configuration Settings Check and update if required
Kinematics Check and update if required
Whole Anodising Visually Inspect
External fasteners Replace
Quality Control Perform Outgoing quality control and provide
System Item Procedure Description
