25
Repeat for the deploy button.
8. Press and hold the stow button, ensure the arms stows completely. Release the button to stop the movement.
9. Whilst moving the arm, press and hold the pause button, ensuring the arm stops responding whilst the button is held
down. Releasing the button will engage movement again.
This completes the acceptance test for the Bravo and Master Arm.
J1
J2
J3
J4
J5
J6
J7
E
C
D
A
B
Deploy Button
Stow Button
