Record K21 - 3 Description; Graphical Overview

Description 3
BAL_K21_EN_3V3_BLA_121-006423019 13 / 44
3 Description
3.1 Graphical overview
K21/22-S
With sliding door
K21/22-P
With pivot wing
K21/22-FM
With fixed glazing
Abbreviation Description Abbreviation Description
A Passage width LH Clearance height
B Floor trim height OKFFB Top edge finished floor
C Installation diameter of floor
trim
OKRFB Top edge unfinished floor
D Recess depth Q Total diameter
G Passage height S Central passage width with
sliding door
I Cladding height T Exterior diameter
J Total height U Interior diameter
LB Clearance width
