Description 3
BAL_K21_EN_3V3_BLA_121-006423019 17 / 44
17 Foot protection sensor radial protective sliding wing
18 Vertical light barriers drum edges
19 Monitoring contact night shield (UW-NAS)
20 Main power switch (UW-HAS)
21 Control unit BDE-D-KTA
22 Key-operated switch BDE-V
23 Key-operated emergency switch
24 Emergency stop switch
25 Disabled person button
26 Start button
27 Key pivot contact
28 Contact mat blocked segment
29 Key-operated switch
30 Sliding door drive STA 20
31 Sliding door control unit BDE-D-STA
32 Traffic light red / green (alternatively in the standing column)
33 Turn key switch night shield
34 Light barriers pivot wing joints
35 Emergency open button
36 Contact mat exit direction
37 Contact mat entrance direction
38 On-site code card reader (1x interior and 1x exterior)
39 Horizontal sensor strip (opening and closing side)
40 Lock mechanism status indicator VRM rotor
41 Door position indicator TPA rotor
42 Lock mechanism status indicator VRM radial protective sliding wing
43 Door position indicator TPA radial protective sliding wing
44 Drive gear box (subfloor)
45 Safety sensors (shearing edge / crushing edge)
46 Electromagnetic lock with bolt contact
47 Turnstile lock
48 “Open position” night shield wing
49 FPC service outlet
50 Lighting
51 Combination sensors
