Red Jacket Quick-Set P75S1T2 - Replacing the Capacitor in Packer

4” Standard Pump Installation, Operation & Service Manual Replacing the Capacitor in Packer
36
Replacing the Capacitor in Packer
DANGER! Always disconnect, lock out, and tag the power before starting to service the pump.
When servicing unit use non-sparking tools and use caution when removing or installing equipment to
avoid generating a spark.
Serious injury or death can result from using a generic-type capacitor. Generic-type capacitors do not
contain internal bleed resistors.
NOTICE: Capacitor is 440V, 17.5 µF continuous duty with internal bleed resistor for 1/3 and 3/4 HP
models. Capacitor is 440V, 25 µF continuous duty with internal bleed resistor for 1-1/2 HP models.
1. Remove wiring compartment cover.
2. Remove retaining clip.
3. Pull out capacitor.
4. Pull quick connectors.
5. Push connectors onto new capacitor.
6. Push capacitor into wiring compartment. Clip into place.
7. Lubricate capacitor cover o-ring with petroleum jelly and reinstall cover. Do not use thread sealant. Torque to
35 ft-lb (50 N•m).
OFF
