4” Standard Pump Installation, Operation & Service Manual Fuel Compatibilities
4
Fuel Compatibilities
Pumps are designed to operate in a Class 1, Group D atmosphere and in accordance with CENELEC standard
and the European Directive 94/9/EC “Equipment for Potentially Explosive Atmoshpere” (II 2G Ex IIA T4).
The Standard STP is designed to be compatible with 100 percent gasoline, or diesel and 80 percent gasoline with
20 percent methanol, ethanol, TAME, ETBE, or MTBE. All UMPs having the model numbers including the AG
prefix are designed to be compatible with 100 percent gasoline, methanol, diesel, 90 percent ethanol with 10
percent gasoline and 80 percent gasoline with 20 percent TAME, ETBE, or MTBE (See Table 1 for UMP models
and working parameters).
The Quick-Set feature is an adjustable column pipe and electrical conduit that allows the overall length to be
adjusted to a wide range of overall pump lengths. By loosening a collet on the column pipe, the length of the ump
may be varied by extending or retracting the column pipe.
Four Quick-Set sizes are available, covering most pump length requirements, for precise lengths, see the sizing
charts within this chapter.
Leak Detector Installation and Manifold Dimensions
Figure 1 shows several manifold views of the Standard pump.
All Models of the Standard STP are UL Listed for the Following Fuel Compatibility
Diesel Gasoline
Gasoline and up to
15%
Ethanol
15%
Methanol
20%
MTBE
20%
ETBE
20%
TAM E
Table 1.- Maximum Specific Gravity and Maximum Viscosity
UMP Model
Maximum Specific
Gravity Maximum Viscosity
AGUMP33R1, UMP33R1 .95 70SSU at 60°F (15°C)
AGUMP75S1, UMP75S1 .95 70SSU at 60°F (15°C)
AGUMP150S1, UMP150S1 .95 70SSU at 60°F (15°C)
AGUMP75S3-3, UMP75S3-3 .95 70SSU at 60°F (15°C)
AGUMP150S3-3, UMP150S3-3 .95 70SSU at 60°F (15°C)
X3AGUMP150S1, X3UMP150S1 .87 70SSU at 60°F (15°C)
AGUMP75S17-3, UMP75S17-3 .95 70SSU at 60°F (15°C)
AGUMP150S17-3, UMP150S17-3 .95 70SSU at 60°F (15°C)
X4AGUMP150S17, X4UMP150S17 .86 70SSU at 60°F (15°C)
X4GUMP150S3, X4UMP150S3 .86 70SSU at 60°F (15°C)
