Red Jacket Quick-Set P75S1T2 - Specifications

4” Standard Pump Installation, Operation & Service Manual Specifications
8
Specifications
Table 2 shows the adjustable pump lengths by model
Table 2.- Distance From Eye Bolt to Inlet
MODEL#
COMPRESSED EXTENDED
in mm in mm
P33R1T1, AGP33R1T1 68.5 1740 95.5 2426
P33R1T2, AGP33R1T2 91.5 2324 125.5 3188
P33R1T3, AGP33R1T3 125.5 3188 192.5 4890
P33R1T4, AGP33R1T4 125.5 3188 159.5 4051
P75S1T1, AGP75S1T1 71.0 1803 98.0 2489
P75S1T2, AGP75S1T2 94.0 2387 128.0 3251
P75S1T3, AGP75S1T3 128.0 3251 195.0 4953
P75S1T4, AGP75S1T4 128.0 3251 162.0 4115
P150S1T1, AGP150S1T1 73.5 1865 100.5 2551
P150S1T2, AGP150S1T2 96.5 2450 130.5 3313
P150S1T3, AGP150S1T3 130.5 3313 197.5 5015
P150S1T4, AGP150S1T4 130.5 3313 164.5 4177
X3P150S1T1, X3AGP150S1T1 74.5 1887 101.5 2573
X3P150S1T2, X3AGP150S1T2 97.5 2471 131.5 3335
X3P150S1T3, X3AGP150S1T3 131.5 3335 198.5 5037
X3P150S1T4, X3AGP150S1T4 131.5 3335 165.5 4199
P75S3-3T1, AGP75S3-3T1 73.0 1853 100.0 2539
P75S3-3T2, AGP75S3-3T2 96.0 2437 130.0 3301
P75S3-3T3, AGP75S3-3T3 130.0 3301 197.0 5003
P75S3-3T4, AGP75S3-3T4 130.0 3301 164.0 4165
P150S3-3T1, AGP150S3-3T1 75.0 1907 102.0 2592
P150S3-3T2, AGP150S3-3T2 98.0 2491 132.0 3354
P150S3-3T3, AGP150S3-3T3 132.0 3354 199.0 5056
P150S3-3T4, AGP150S3-3T4 132.0 3354 166.0 4218
X4P150S3T1, X4AGP150S3T1 75.5 1920 102.5 2606
X4P150S3T2, X4AGP150S3T2 98.5 2504 132.5 3368
X4P150S3T3, X4AGP150S3T3 132.5 3368 199.5 5073
X4P150S3T4, X4AGP150S3T4 132.5 3368 166.5 4232
P75S17-3T1, AGP75S17-3T1 72.0 1828 99.0 2514
P75S17-3T2, AGP75S17-3T2 95.0 2412 129.0 3276
P75S17-3T3, AGP75S17-3T3 129.0 3276 196.0 4977
P75S17-3T4, AGP75S17-3T4 129.0 3276 163.0 4139
P150S17-3T1, AGP150S17-3T1 74.0 1878 101.0 2564
P150S17-3T2, AGP150S17-3T2 97.0 2462 131.0 3326
P150S17-3T3, AGP150S17-3T3 131.0 3326 198.0 5028
P150S17-3T4, AGP150S17-3T4 131.0 3326 165.0 4189
