4” Standard Pump Installation, Operation & Service Manual Packer-Manifold Assembly Parts
42
Table 9.- Packer-Manifold Assembly Parts List
Item (Ref.
Figure 35 &
Figure 36) Part No. Description DOM INT’L
1 026-205-1 Screw - 1/2-13 x 1-1/4 UNC 2 2
2 027-031-1 Plug - Pipe 1/4” NPT 2 2
3 027-084-1 Plug - Pipe 3/8” NPT 1 1
4 026-176-1 Screw - 3/8-16 x 3/4 UNC 2 2
5 188-241-5 Siphon Check Valve AG 1 1
6 027-086-3 Plug - Pipe 2” NPT (Single Box Only) 1 1
6 067-281-5 Plug - Ass’y. Conduit Box (Dual Box Option Not Shown) 2 2
7 144-229-5 Kit - 2 Wire Electrical Connector & Dual Conduit Box Petro (Not Shown) 1 1
7 144-221-5 Kit - 3 Wire Electrical Connector & Dual Conduit Box Petro (Not Shown) 1 1
7 144-222-5 Kit - 3 Wire Electrical Connector & Dual Conduit Box AG (Not Shown) 1 ---
8 113-084-5 P33R1 Capacitor Cover With O-ring 1 ---
8 113-085-5 P75S1 Capacitor Cover With O-ring 1 ---
8 113-319-5 P150S1 Capacitor Cover With O-ring 1 ---
8 113-536-5 X3P150S1 Capacitor Cover With O-ring 1 ---
8 113-543-5 X4P150S3 Capacitor Cover With O-ring --- 1
8 113-320-5 P150S3-3 Capacitor Cover With O-ring --- 1
8 113-479-5 AGP33R1 Capacitor Cover With O-ring 1 ---
8 113-480-5 AGP75S1 Capacitor Cover With O-ring 1 ---
8 113-481-5 AGP150S1 Capacitor Cover With O-ring 1 ---
8 113-538-5 X3AGP150S1 Capacitor Cover With O-ring 1 ---
8 113-544-5 P75S17-3 Capacitor Cover With O-ring --- 1
8 113-545-5 P150S17-3 Capacitor Cover With O-ring --- 1
8 113-546-5 X4P150S17 Capacitor Cover With O-ring --- 1
8 113-599-5 AGP75S3-3 Capacitor Cover With O-ring --- 1
8 113-600-5 AGP150S3-3 Capacitor Cover With O-ring --- 1
9 072-190-1 Capacitor Cover O-ring Buna (-233) PETRO 1 1
9 072-543-1 Capacitor Cover O-ring Viton (-233) AG 1 1
10 264-138-5 2-Wire Replacement Packer Ass’y. PETRO 1 1
10 264-142-5 2-Wire Replacement Packer Ass’y. AG 1 1
10 264-141-5 3-Wire Replacement Packer Ass’y. PETRO 1 1
11 111-092-5 Capacitor 17.5 µF 1 1
11 111-661-5 Capacitor 25 µF 11
