4. Remove the 2 screws on the top vibration damping
system.
5. Discard the 2 old screws.
6. Remove the body from the frame.
7. Install in the opposite sequence.
CAUTION: Use 2 new screws when you
install the frame to the top vibration damping
system.
7.13.2 To remove and install the top vibration
damping unit
1. Remove the frame. Refer to
To remove and install
the frame on page 34
.
2. Remove the screw, washer and the vibration
damping unit.
3. Discard the old screw.
4. Install a new screw and the washer but do not
tighten the screw fully.
5. Turn the top vibration damping unit clockwise until it
stops.
6. Tighten the screw fully.
1662 - 003 - 04.11.2021 Repair instructions - 35
