Reflex Variomat VS 1 User Manual

Description of the device
10
— English Variomat 1 — 06.07.2016 – Rev. B
4.3
Identification
4.3.1
Nameplate
The nameplate provides information about the manufacturer, the year of manufacture, the manufacturing number and the technical
data.
Information on nameplate
Meaning
Type Device name
Serial No. Serial number
min. / max. allowable pressure P Minimum/maximum
permissible pressure
max. continuous operating
temperature
Maximum temperature for
continuous operation
min. / max. allowable temperature
/ flow temperature TS
Minimum / maximum
permissible temperature /
TS flow temperature
Year built Year of manufacture
min. operating pressure set up on
shop floor
Factory-set minimum
operating pressure
at site Set minimum operating
pressure
max. pressure saftey valve factory -
aline
Factory-set opening
pressure of the safety
valve
at site Set opening pressure of
the safety valve
4.3.2
Type code
No.
Type code (example)
1 Control unit designation
2 Number of pumps
Variomat VS 1, VG 500 l, VF 500 l
3 "VG" primary tank 1 2 3 4 5 6
4 Nominal volume
5 "VF" secondary tank
6 Nominal volume
