Modifying the controller's start routine
Note!
For handling the operator panel see chapter
9.1 "Operator panel" on page 50
The start routine is used to set the required parameters for the device commissioning. It commences with the first activation of the
controller and can be run only once. Parameters can be changed or checked in the customer menu after the start routine has terminated
see chapter 7.6 "Parametrising the controller in the Customer menu" on page 42 .
Notice!
Plug in the contact plug to provide power (230 V) to the controller.
You are now in Stop mode. The "Auto" LED on the operator panel has extinguished.
Variomat
Standard software with various languages.
Language
Prior to commissioning, read the entire operating manual and verify the proper assembly.
Read the operating manual!
Enter the value for the minimum operating pressure.
Calculating the minimum operating pressure, see chapter 7.2 "Determining the P
0
minimum operating pressure for the controller" on page 36 .
Min. op. pressure
Change the flashing display items for "Hour", "Minute", and "Seconds" to the
current time.
The time of an alarm will be stored in the fault memory.
Time
Change the flashing display items for "Day", "Month", and "Year" to the current date.
The date of an alarm will be stored in the fault memory.
Date
the "VG" primary tank.
For the primary tank data, see the name plate or see chapter 5 "Technical data" on
page 14 .
GB = 0093 kg
To Next Page
