Null balancing of the level sensor.
•
The controller checks whether the level measuring signal matches the dimensional
data of the "VG" primary tank. The primary tank must be fully emptied, see
chapter
6.3.6 "Fitting the level sensor" on page 26.
1 % 1.7 bar
Null balancing!
Upon successful conclusion of the null balancing, confirm with "OK" on the controller
operator panel.
0 % 1.0 bar
Null balancing concluded
successfully
Select "Yes" or "No" on the controller
display and confirm with "OK" on the controller
operator panel.
Cancel null balancing?
No
yes:
The "VG" primary tank is fully emptied and the device is installed as per the
instructions.
• If null balancing is still not possible, confirm with "Yes".. The start routine is
terminated. Use the customer menu to repeat the null balancing, see
chapter 7.6 "Parametrising the controller in the Customer menu" on page 42.
• Contact your Reflex Customer Service, see chapter 12.1 "Reflex Customer
Service" on page 64.
no:
The start routine restarts.
• Check the prerequisites for the commissioning, see chapter 7.1 "Checking the
requirements for commissioning" on page 36.
This message appears on the display only after null balancing has been successful.
Select "Yes" or "No" on the
controller display and confirm with "OK" on the controller
operator panel.
Terminate routine?
No
yes:
The start routine is terminated, the device automatically switches to Stop mode.
no:
The start routine restarts.
The level indication is at 0
%. 0 % 2.0 bar
STOP
Notice!
After successful conclusion of the start routine, you are in Stop mode.
Do not yet switch to Automatic mode.
