TYPICAL 12 VOLT HELM SWITCH PANEL
HORN protects the horn circuitry.
TOWER UP & DOWN controls the PowerTower ac-
tuators
UNDERWATER LTS.- protects the transom mounted
light (under platform) circuit.
FRESH WATER- protects the pressure fresh water sys-
tem pump.
HATCH.- protects the engine hatch motor circuitry.
NAV/ANC. protects the port and starboard deck navi-
gation and anchor lights.
COCKPIT LTS- activates the LED cockpit lights in-
stalled on the deck.
DOCKING LTS.- protects the hull mounted docking
light circuitry.
BILGE PUMP protects the bilge pump circuitry.
BILGE BLOWER protects the bilge blower that evacu-
ates engine compartment fumes.
Note: A portion of the helm switch panel protection is
for optional items that may not be on board your vessel.
