20
Chapter 4
TYPICAL DC (12 VOLT) WIRING COLOR CODE & SIZES
BLACK 16,14,12,10,8,6,4,2,2/0,40 GROUNDS
BLACK/WHITE 16 HALON INDICATOR
BLACK/YELLOW 10,16
GRD. DIESEL TRANSFER PUMP,
MERC DIESEL STOP CIRCUIT
BLACK/WHITE 10 HALON MAIN GRD. FEED
BROWN/BLACK 10 MACERATOR, SUN ROOF
BROWN 10 SUN ROOF
BROWN 14 AFT BILGE PUMP-MANUAL
BROWN/WHITE 14 AFT BILGE PUMP-AUTO
BROWN/RED 14 FWD. BILGE PUMP-AUTO
BROWN/BLUE 14 FWD. BILGE PUMP-MANUAL
BROWN/PINK 16 CO DETECTOR
BROWN/BLACK 16 SHOWER SUMP PUMP
YELLOW 12,10 BLOWER
YELLOW/WHITE 16 HEAD VENT FAN MOTOR
YELLOW/BLACK 16 STEREO MEMORY
YELLOW/RED 14 ENGINE START CIRCUIT
Note: e list above applies to a number of vessels. Vessel components/wiring speci cations may vary depending
on the model.
