AVOID POSSIBLE DAMAGE TO THE EYES
DUE TO ELECTROMAGNETIC ENERGY.
WHEN RADAR IS TRANSMITTING
DO NOT LOOK DIRECTLY AT THE ANTENNA
AT CLOSE RANGE.
Radar Operation
Read the radar operator’s manual for learning all the fea-
tures of the radar component. It is a good idea to use
the manual along side the chartplotter to learn the basic
radar operation. At that point you can branch out with
the manual on the secondary functions of the radar. Pay
special attention to all safety and warning labels in the
operatior’s manual.
Since the optional radar unit is part of the vessel elec-
tronic marine network you will be able to use the chart-
plotter as your network screen and have the capability
to overlay the radar image on the chartplotter map page.
The closed array radar unit is normally mounted on the
power tower along with the TV antenna.
