Page #37 background imageLoading...
Page #37 background image
RCF manual Chapter 14 Display handling 37
Number of
parameter
Description
Factory
setting (FS)
17 Output signal for actuator connected to AO2:
0=0…10 V
1=2…10 V
2=10…2 V
3=10…0 V
0
18 Period time for heating actuator if thermal
actuators.
60 s
19 Period time for cooling actuator if thermal
actuators.
60 s
20 Run time for heating actuator with increase/decrease actuators. 120 s
21 Run time for cooling actuator with increase/decrease actuators. 120 s
22 Time (in hours) between exercise of heating actuator. 23
23 Time (in hours) between exercise of cooling actuator. 23
24 Setpoint or actual value shown in display:
0=Actual, setpoint when changing setpoint value
1=Actual, setpoint displacement when changing setpoint displacement
2=Setpoint
3=Only setpoint displacement
2
25 Configuration of fan control:
0=No control
1=The fan is controlled by the heating requirement
2=The fan is controlled by the cooling requirement
3=The fan is controlled by both the heating and cooling requirement
When using an electric heater this parameter should only be set to 1 or 3,
otherwise there is a risk of overheating.
3
26 Start signal in % for controller output, heating or cooling, for fan speed
1.
20 (5 when
using electric
heater)
27 Start signal in % for controller output, heating or cooling, for fan speed
2.
60
28 Start signal in % for controller output, heating or cooling, for fan speed
3.
100
29 Hysteresis for start/stop of fans in % of controller output. 5
30 Number of fan speeds. 3
31 Fan speed in Auto mode:
0 = The lowest fan speed is ”stop”
1 = The fan will never stop except when in the controller off mode. The
lowest possible speed is limited to the lowest speed of the fan.
1
32 Temperature compensation on AI1. 0 K
33 Temperature compensation for internal room sensor. 0 K
34 Maximum permitted upward setpoint offset. Settable value=0...13 K. 13 K
35 Maximum permitted downward setpoint offset. Settable value=0...17 K. 17 K
36 NO/NC* digital input 1:
0=NO
1=NC
0
37 NO/NC* universal input 1:
0=NO
1=NC
0
38 NO/NC* digital output 4:
0=NO
1=NC
1
39 NO/NC* digital output 5:
0=NO
1=NC
1
