Regin RCF Series User Manual

38 Chapter 14 Display handling RCF manual
Number of
parameter
Description
Factory
setting (FS)
40 Manual/Auto heating output signal:
0=Off
1=Manual
2=Auto
2
41 Manual/Auto cooling output signal:
0=Off
1=Manual
2=Auto
2
42 Heating output signal in manual mode. 0
43 Cooling output signal in manual mode. 0
44 Model. -
45 Major version. -
46
Branch version.
-
47
Launched version or beta version.
-
48
Revision.
-
49 Display backlight low 10
50 Display backlight high 30
51 EXOline PLA-address FS
52 EXOline ELA-address FS
53 Modbus address 254
54 Parity and stop bits for Modbus communication:
0 = 8N2
1 = 8O1
2 = 8E1
3 = 8N1
2
55 Modbus timeout for characters (t1.5), in ms. Should be 3.5 times a
character, ie. at least 2 ms.
2
56 Response lag Modbus (t3.5), in ms. Should be 3.5 times a character, ie.
at least 5 ms.
5
57 Communication protocol:
0 = Automatic EXOline or Modbus
1 = BACnet MS/TP
0
58 BACnet MS/TP MAC address: 0-127 FS (0-99)
59 BACnet MS/TP, device id, the 4 lowest digits. Ex. 4567 in 1234567 FS
60
BACnet MS/TP, device id, the 3 highest digits. Ex. 123 in 1234567
FS
61
BACnet MS/TP, maximum number of master units
127
62 Speed for communication protocol:
0 = 9600 bps
1 = 19200 bps
2 = 38400 bps
3 = 76800 bps
0
63 Set communication parameters to factory settings (does not apply to
addresses):
1 = Factory settings (EXOline/Modbus@9600 )
0
64 Basic setpoint for RCF, 5…50°C (0…100°C with Regio tool
©
) 22
