10A-47
ENGINE AND CYLINDER BLOCK ASSEMBLY
Engine oil: Draining - Refilling
F9Q
10A
a Remove the engine oil drain plug (2) using the (Mot.
1018).
a Let the engine oil run into the oil recovery contai-
ner.
a Remove the drain plug seal.
a Refit:
-a new seal (3) on the sump drain plug,
-the drain plug on the sump.
a Torque tighten the drain plug (20 N.m).
a Clean the traces of oil around the drain plug so that
any possible leaks can be detected.
a Remove the oil recovery container.
III - FILLING
a Fill the engine with oil, observing the recommended
amount.
a Wait at least 10 minutes.
a Check the oil level using the dipstick.
a Adjust the engine oil level if necessary.
a Refit:
- the « filler cap - dipstick » assembly,
- the engine undertray.
19120
113765
